Binding Post Connectors
The original 5-WAY Binding Post Connector is the first choice of electrical equipment manufacturers, design engineers and technicians. They are available in hex or fluted thumbnuts, single and double assembly, and in a wide variety of colors with ratings of 15 and 30 ampere.
The limited opening captive thumbnuts allow enough space to make connections, yet reduce the possibility of accidental contact with electrically energized surfaces. The current carrying parts are available in gold, tin or nickelplate-brass. There are multiple ways to connect 5-WAY Binding Post Connectors — including soldering — for maximum use flexibilit.
Single Assembly
BP21 Series
Single Assembly
6-32 Amperage/Stud Thread Size
Available in Black, Yellow, Red, Blue, Green, or White
Gold Nickel Plating
Rating: 15A, 1000V Working
Fluted Nut Type
Double Assembly
BP21-2 Series - Obsolete
Double Assembly
6-32 Amperage/Stud Thread Size
Available in Red-Red, Black-Black or Black-Red
Gold Nickel Plating
Rating: 15A, 1000V Working
Fluted Nut Type
BP30 Series
Single Assembly
8-32 Amperage/Stud Thread Size
Available in Black, Yellow, Red, Blue, Green, or White
Gold Nickel Plating
Rating: 30A, 1000V Working
Hex Nut Type
BP30-2 Series - Obsolete
Double Assembly
8-32 Amperage/Stud Thread Size
Available in Red-Red, Black-Black, Black-Red
Gold Nickel Plating
Rating: 30A, 1000V Working
Hex Nut Type
BP30-10 Series
Single Assembly
10-32 Amperage/Stud Thread Size
Available in Black, Yellow, Red, Blue, Green, or White
Gold Nickel Plating
Rating: 30A, 1000V Working
Hex Nut Type
BP30-2xx10 Series - Obsolete
Double Assembly
10-32 Amperage/Stud Thread Size
Available in Red-Red, Black-Black, Black-Red
Gold Nickel Plating
Rating: 30A, 1000V Working
Hex Nut Type
BP30GP10 Series
Single
Assembly
10-33 Amperage/Stud Thread Size
All Metal Grounding
Nickel Plating
Rating: 30A, 1000V Working
Hex Nut Type
