VC Series Medium Voltage Vacuum Contactor
Looking to buy? Contact our sales team today!

Low & Medium Voltage Vacuum Contactor

VC Series

Voltage: Up to 3.6kV  |  Amperage 600 max | <1A Chopping Current  |  Auxiliary Contacts  |  Opening Time 90ms  |  Closing Time 17ms

The Joslyn Clark USAVAC low voltage vacuum contactors and starters are ideal for applications from 200V to 3,600V and motor ratings for 50 to 3700HP depending on voltage.

3600V, 3 Phase, 600A Vacuum Contactor Rated 2,400HP/2,300V and 3,700HP/3,300V

1,500V, 3 Phase, 320A Vacuum Reversing Contactor Rated 250HP/460V and 850HP/1,500V

VC Series Contactors and Starters incorporate many useful features to insure ease of maintenance, versatility, and reliability. The contactor can be assembled or dismantled without the use of any tools. The control module contains the coil and auxiliary contacts wired to a terminal block and is easily removed for checking or immediate replacement. The phase assembly is a vacuum interrupter containing the power switching contacts.


Features
  • Front Accessible
  • Quiet Operation
  • Energy efficient control module
  • Mounts in any plane
  • Compact, Lightweight
  • Fully phase insulated
  • Tamper resistant, dust protected
  • Self-adjusting power contacts
  • Rugged modular construction
