Straight Sleeve Bearings

Standard
Standard with Lubrication Groove
Standard with Carbon Steel Outer Sleeve
Standard with Lubrication Groove & Carbon Steel Outer Sleeve

Thomson Nyliner™ engineers and manufactures four types of straight sleeve bearings to provide high radial and static load capacity in limited spaces. These straight sleeve bearings share many characteristics, including the axial compensation gap, a standard feature of the Thomson Nyliner bearing. This gap allows expansion and contraction in reaction to environmental factors, such as humidity or temperature. The gap will absorb most of any fluctuation of the plastic sleeve bearings.

Straight sleeve bearings are designed especially for applications where press fitting into a housing bore is the most practical bearing retention method. The standard straight sleeve bearings are simple plastic sleeves with no lubricant groove or outer sleeve. Thomson also provides an option to add a carbon steel or nickel-plated steel sleeve to the standard straight sleeve bearing. The additional outer sleeve allows the bearing to stand up to mildly corrosive environments. Standard straight sleeve bearings and straight sleeve bearings with lubrication grooves require some external means of retaining the bearing in the housing bore.

Clearances

The minimum diametral shaft to bearing clearances normally recommended is .001˝ for bearing I.D. sizes to 1.000˝; .0015˝ for I.D. sizes from 1.000˝ to 1.250˝; and .002˝ for I.D. sizes over 1.250˝. These clearances are recommended to allow proper running clearance for trouble-free operation. Bearings will expand slightly due to frictional heat and moisture absorption. The majority of this expansion is accommodated by the compensation gap. Changes in wall thickness are minimal due to the thin wall construction of Thomson Nyliner bearings.

These recommended running clearances can be reduced if Plus materials are used. These Thomson Engineering Polymers have significantly lower coefficients of linear thermal expansion than standard bearings. When bearings with nickel-plated sleeves are used, the shaft diameter should be reduced by .001˝ to compensate for the reduction in bearing I.D. by the addition of the nickel-plating to the steel sleeve.

Standard Straight Sleeve Bearings
Part
Number
Nominal Bearing Inner Diameter Bearing Inner Diameter Housing
Bore
Bearing Length (+0, -1/64) Minimum Distance Between Retaining Shoulders Retaining Lips Inner Diameter (±.005)
Inner
Diameter
Tolerance
(-.000)
Maximum Shaft Diameter
3L4-D 3/16 .1885 +.001 .1875 .2340 .205 .210 .205
4L6-D 1/4 .2510 +.001 .2500 .2943 .315 .327 .268
5L7-D 5/16 .3135 +.001 .3125 .3810 .370 .385 .335
5L9-D 5/16 .3135 +.001 .3125 .3810 .540 .550 .335
6L8-D 3/8 .3760 +.001 .3750 .4435 .432 .448 .395
8L8-D 1/2 .5010 +.001 .5000 .5685 .432 .448 .520
8L12-D 1/2 .5010 +.001 .5000 .5685 .750 .770 .520
10L12-D 5/8 .6260 +.001 .6250 .6935 .670 .700 .645
10L16-D 5/8 .6260 +.001 .6250 .6935 1.0000 1.030 .645
12L5-D 3/4 .7510 +.001 .7500 .8180 .330 .340 .770
12L12-D 3/4 .7510 +.001 .7500 .8180 .670 .700 .770
14L12-D 7/8 .8760 +.001 .8750 .9385 .670 .700 .893
16L18-D 1 1.0010 +.001 1.0000 1.0935 1.125 1.156 1.020
18L18-D 1 1/8 1.1260 +.001 1.1250 1.2185 1.125 1.156 1.145
20L18-D 1 1/4 1.2510 +.001 1.2500 1.3435 1.125 1.156 1.270
24L24-D 1 1/2 1.5020 +.002 1.5000 1.6245 1.500 1.550 1.540
32L39 2 2.0020 +.003 2.0000 2.1250 2.437 2.470 2.040
48L28-D 3 3.0020 +.004 3.0000 3.1250 1.750 1.770 3.040
Standard Straight Sleeve Bearings With Lubrication Groove
Part
Number
Nominal Bearing Inner Diameter Bearing Inner Diameter Housing
Bore
Bearing Length (+0, -1/64) Minimum Distance Between Retaining Shoulders Retaining Lips Inner Diameter (±.005)
Inner
Diameter
Tolerance
(-.000)
Maximum
Shaft Diameter
4L6 1/4 .2510 +.001 .2500 .2943 .315 .327 .268
5L7 5/16 .3135 +.001 .3125 .3810 .370 .385 .335
6L8 3/8 .3760 +.001 .3750 .4435 .432 .448 .395
8L8 1/2 .5010 +.001 .5000 .5685 .432 .448 .520
9L8 9/16 .5635 +.001 .5625 .6310 .484 .500 .585
10L12 5/8 .6260 +.001 .6250 .6935 .670 .700 .645
12L12 3/4 .7510 +.001 .7500 .8180 .670 .700 .770
14L12 7/8 .8760 +.001 .8750 .9385 .670 .700 .893
16L16 1 1.0010 +.001 1.0000 1.0585 .910 .940 1.020
18L16 1 1/8 1.1260 +.001 1.1250 1.1850 .910 .940 1.145
20L16 1 1/4 1.2510 +.001 1.2500 1.3110 .910 .940 1.270
24L20 1 1/2 1.5020 +.002 1.5000 1.5860 1.148 1.190 1.535
Standard Straight Sleeve Bearings With Carbon Steel Outer Sleeve
Part
Number
Nominal Bearing Size Maximum Recommended
Shaft Diameter
Recommended Housing Bore Limits
Inner Diameter Outer Diameter Length
(+.000 -.010)
Minimum Maximum
4N6-D 1/4 11/32 11/322 .2500 .3430 .3435
5N7-D 5/16 7/16 7/16 .3125 .4370 .4380
6N8-D 3/8 1/2 1/2 .3750 .4990 .5000
8N8-D 1/2 5/8 5/8 .5000 .6240 .6250
10N12-D 5/8 3/4 3/4 .6250 .7490 .7500
12N12-D 3/4 7/8 3/4 .7500 .8740 .8750
14N12-D 7/8 1 1 .8750 .9990 1.0000
16N16-D 1 1-1/8 1-1/8 1.0000 1.1240 1.1250
18N16-D 1-1/8 1-1/4 1-1/4 1.1250 1.2490 1.2500
Standard Straight Sleeve Bearings With Lubrication Groove & Carbon Steel Outer Sleeve
Part
Number
Nominal Bearing Size Maximum Recommended
Shaft Diameter
Recommended Housing Bore Limits
Inner Diameter Outer Diameter Length
(+.000 -.010)
Minimum Maximum
4N6 1/4 11/32 11/322 .2500 .3430 .3435
5N7 5/16 7/16 7/16 .3125 .4370 .4380
6N8 3/8 1/2 1/2 .3750 .4990 .5000
8N8 1/2 5/8 5/8 .5000 .6240 .6250
10N12 5/8 3/4 3/4 .6250 .7490 .7500
12N12 3/4 7/8 3/4 .7500 .8740 .8750
14N12 7/8 1 1 .8750 .9990 1.0000
16N16 1 1-1/8 1-1/8 1.0000 1.1240 1.1250
18N16 1-1/8 1-1/4 1-1/4 1.1250 1.2490 1.2500
